| Net weight |
≈620 g
|
| Auto exposure bracketing |
1 or 2 EV steps, 1/2, 2 or 3 frames in 1/3, 2/3
|
| Autofocus |
Nikon Multi-CAM 1000 TTL phase-detection AF module with 11 focus points (incl. 1 cross-type) and AF-assist illuminator (range 0.5–3 m)
|
| Autofocus modes |
AF-A (auto-servo with predictive tracking), AF-C (continuous-servo), AF-S (single-servo)
|
| Built-in flash |
13/43 in manual flash mode (ISO 100, 20°C), 20°C): approx. 12/39, Guide number approx. 17-18 at ISO 100 in manual flash mode; (ISO 200, m
|
| Continuous shooting |
Continuous high: up to 4.5 fps, Continuous low: 1–4 fps
|
| Crop factor |
1.5x
|
| Dimensions (W x H x D) |
132x103x77 mm
|
| Diopter adjustment |
-2 to +1 m-1
|
| Effective pixels |
12.3 MP
|
| Exposure compensation |
-5 to +5 EV in 1/3 or 1/2 EV steps
|
| Flash exposure compensation |
-3 to +1 EV in 1/3 or 1/2 EV steps
|
| ISO sensitivity |
0.7 or 1 EV (equivalent to ISO 100) below ISO 200, 0.7 or 1 EV (equivalent to ISO 6400) above ISO 3200, ISO 200–3200 in 1/3 EV steps. Can be set approx. 0.3, or approx. 0.3
|
| Interfaces |
HDMI 1.3a with HDMI Type C connector, NTSC/PAL, PTP, USB
|
| LCD monitor |
100% frame coverage, 170° viewing angle, 3-inch low-temperature polysilicon TFT, 920k dots (VGA), brightness adjustment
|
| Lens mount |
Nikon F
|
| Max frame rate |
24 (HD)
|
| Max photo size |
JPEG and RAW 4288×2848
|
| Max recording time per video file |
5 min
|
| Metering |
Color Matrix Metering II (other CPU lenses); Center-weighted: 75% weight to a 6/8/10 mm circle in center; Spot: 3.5 mm circle (approx. 2.5% of frame) centered on selected focus point, TTL metering with 420-pixel RGB sensor: Matrix: 3D Color Matrix Metering II (G and D lenses)
|
| Metering range |
20°C: Matrix/center-weighted: 0–20 EV, f/1.4 lens, ISO 100, Spot: 2–20 EV
|
| Mirror |
Quick-return type
|
| Operating conditions |
0 to +40°C, humidity <85% (non-condensing)
|
| Photo file types |
JPEG, NEF (compressed RAW)
|
| Processor |
EXPEED image processing system
|
| Sensor size |
23.5×15.6 mm
|
| Sensor type |
APS-C CMOS
|
| Shooting modes |
A, Auto (Auto, Auto (flash off)), Close-up, Landscape, M, Night Portrait), P, S, Scene modes (Portrait, Sports
|
| Shutter |
Electronically controlled vertical-travel shutter
|
| Shutter speed range |
1/4000 to 30 sec in 1/3 or 1/2 EV steps, Bulb (requires optional ML-L3 IR remote)
|
| Storage media |
SD (SDHC compatible); Eye-Fi (requires approval)
|
| Video |
HD (1280×720) 24p
|
| Video file types |
AVI (Motion-JPEG)
|
| Video recording sizes |
1280×720 at 24 fps, 320×216 at 24 fps, 640×424 at 24 fps
|
| Viewfinder |
-1 m-1), approx. 0.94x magnification (50mm f/1.4 at infinity, approx. 96% coverage horizontal and vertical, Optical SLR pentaprism viewfinder
|
| White balance |
12 manual modes with fine-tuning, Auto (TTL WB using main image sensor and 420-pixel RGB sensor), color temperature selection, preset WB
|
| White balance bracketing |
2 or 3 EV steps; ADL bracketing (Active D-Lighting): 2 frames (with ADL and without), 2 or 3 frames in 1
|
| X-sync |
1/200 sec
|
