Seetec Atem215S quad monitor

Category:
Brand:

Seetec Atem215S is a 21.5″ 1920×1080 quad-split monitor with 4× 3G-SDI inputs/outputs, HDMI input, RS485/GPI control, Rec.709 calibration, and AC or V-mount power.

51,00  / day

Clear dates

Seetec Atem215S quad-split monitor with Full HD resolution features four 3G-SDI inputs and outputs, one HDMI input, and RS485/GPI control interfaces. The device supports the Rec.709 color standard and professional monitoring features. The 21.5″ screen has 1920×1080 resolution and accurate color reproduction for a natural, clear image. Brightness is 250 cd/m², contrast 1000:1, and a wide 178° viewing angle ensures good visibility from different positions. Power can be supplied from AC or V-Mount batteries.

Included: Seetec Atem215S monitor, protective case, sun hood, power adapter.

Battery

V-Mount

Inputs

4x 3G-SDI, GPI, HDMI, RS485, USB

Outputs

3.5 mm mini-jack, 4x 3G-SDI, RS485

Net weight

4.27 kg

Aspect ratio

16:9

Brightness

250 cd/m²

Contrast

1000:1

Dimensions (W x H x D)

511.6×355.6×23.3 mm (without bracket)

Loop-through

Yes

Power system

battery, Mains

Quad-split

Yes

Screen resolution

1920×1080

Screen size

21.5"

Signal conversion

Not supported

Supported signal formats

1080i 60/59.94/50, 1080p 60/59.94/50/30/29.97/25/24/24sF/23.98/23.98sF, 2048x1080i 60/59.94/50, 480i/576i/480p/576p, 720p 60/59.94/50/30/29.97/25/24/23.98, 720p 60/59.94/50/30/29/25/24/23.98, HDMI: 1080p 60/59.94/50/30/29.97/25/24/23.98, SDI: 2048x1080p 60/59.94/50/30/29.97/25/24/23.98

Viewing angle

89°/89°
